B5

• Performance

Max Throughput: Up to 1.5 Gbps IP aggregate UL/DL (1.7 Gbps PHY)
•Low Latency: <1 ms in Auto Mode •Wireless Protocols: TDMA, TDMA-FD, Auto-TDMA Radio •MIMO & Modulation: 4×4:4 MIMO OFDM up to 256QAM •Bandwidth: Single or Dual 20/40/80 MHz channels •Frequency Range: 5150-5875 MHz restricted by country of operation (*new* US/FCC 5600-5650 support) •Max Output Power: 30 dBm (2-stream), 27 dBm (4-stream) •Sensitivity ( MCS 0 ): -87 dBm @ 80 MHz -90 dBm @ 40 MHz -93 dBm @ 20 MHz Antenna •Gain: 25 dBi •Beamwidth ( 3dB ): 8° (HPOL and VPOL) •Elevation Adjust: ±20° mechanical adjust •Front-to-Back Ratio: >30 dB
•Cross-Polar Isolation: >20 dB
•Polarization: Dual-linear (horizontal & vertical)
Power
•Max Power Consumption: 20W
•System Power Method: 48 V DC 802.3 at compliant power injectors
•System Lightning & ESD Protection: 6 kV
•PoE Power Supply: Passive POE compliant, 48-56 V Power over Ethernet supply with IEC61000-4-5 surge protection
Physical
•Dimensions: Diameter – 442 mm (17.4”); Depth – 362 mm (14.3”) with bracket
•Weight: 4.9 kg (10.8 lbs) with bracket
•Enclosure Characteristics: Single enclosure with radome Outdoor UV stabilized plastic Painted steel bracket plate
•Wind Survivability: 200 km/h (125 mph)
•Wind Loading: 39 kg @ 160 km/h (86 lbs @ 100 mph)
•Mounting: Pole mounting kit included for 30mm (1.18”) to 90mm (3.54”) OD pipes

• Environmental

Outdoor Ingress Protection Rating: IP67
•Operating Temperature: -40°C to +55°C (-40°F to 131°F)
•Operating Humidity: 5 to 100% condensing
•Operating Altitude: 4,420 m (14,500’) max
•Shock & Vibration: ETS 300-019-2-4 class 4M5
Features
•Gigabit Ethernet: 10/100/1000-BASE-T
•Dual Link Operation: 2 independent dual-stream radios operating on non-contiguous frequencies;
Automatic load balancing of traffic across 4 total MIMO streams with individual stream encoding up to 256 QAM
•Management Services: Mimosa cloud monitoring and management; SNMPv2 & Syslog legacy monitoring; HTTPS; HTML 5 based Web UI; 2.4 GHz 802.11b/g/n radio for local management access
•Smart Antenna Alignment: Hands-free dedicated 2.4 GHz WiFi management radio
•Smart Spectrum Management: Active scan monitors/logs ongoing RF interference across channels (no service impact); Dynamic auto-optimization of channel and bandwidth use
•Security: 128-bit AES PSK with hardware acceleration
•QoS: Supports 4 pre-configured QoS levels
•GPS Location: GNSS-1 (GPS + GLONASS)
•Collocation Synchronization: 1PPS GPS TX/ RX synchronization for collocated co-channel radios; Adjustable up/downstream bandwidth ratio
Regulatory + Compliance
•Approvals: FCC Part 15.407, IC RSS210, CE, ETSI 301 893/302 502
•RoHS Compliance: Yes
•Safety: UL/EC/EN/ 60950-1 + CSA-22.2
